Technical data for X2CrNiMoN17-13-3 cold-heading steel wire, with specification standard ISO 4954. Review the current grade’s chemical composition, mechanical properties, and related technical requirements.
Other delivery conditions may be agreed at the time of enquiry and order.
a X=applicable, -=not applicable. b If agreed at the time of the enquiry and order
2. Chemical composition
Table D.2 - Chemical composition of stainless steel grades (applicable to cast analysis)
Designation
% mass fraction a
Steel name
ISO steel number
C
Si
Mn
P
S
Cr
Ni
Mo
N
Cu
Others
X2CrNiMoN17-13-3
4429-316- 53-I
0,030
1,00
2,00
0,045
0,015
16,5 to 18,5
10,5 to 13,0
2,50 to 3,00
0,12 to 0,22
1,00
—
3. Mechanical properties
Table D.6 - Mechanical properties of martensitic stainless steels under specified delivery conditions
TECHNICAL NOTE
Application and ordering note
Chemical composition, mechanical properties, tolerances and delivery condition must be confirmed against the applicable standard edition, customer drawing and order specification.
